Materials and Conductivity: Why Terminal Block Quality Matters

This is an excellent question that directly addresses the core of electrical system reliability. Why terminal block quality so important?because its the key for  integrity, stability, and safety of the "conductive circuit." We can delve into this matter from several dimensions: materials, design, manufacturing process, and practical implications.

1. Materials: The Physical Basis of Conductivity

Conductivity is primarily determined by the material. High-quality terminal blocks are made from materials with excellent conductivity and undergo necessary surface treatments.

Main material (conductive sheet):

Premium Options: High-purity oxygen-free copper (e.g., TU1) or copper alloys (e.g., brass, phosphor bronze). These materials exhibit low resistivity and excellent conductivity, while phosphor bronze also offers superior elasticity and fatigue resistance, ensuring long-term contact pressure maintenance.

Low-quality materials: Using recycled copper with high impurities, copper-clad aluminum, or even iron coated with copper. These materials exhibit high electrical resistance, severe heat generation, and are prone to corrosion, posing significant safety hazards.

Plating layer: Key corrosion-resistant and contact-enhancing layer.

Tinning: The most common method, with moderate cost, effectively prevents copper substrate oxidation while maintaining excellent solderability and contact.

Silver plating: Offers the best conductivity and strong oxidation resistance, commonly used in applications requiring extremely low contact resistance or high-frequency signals (though silver can sulfidize in sulfide environments).

Nickel/Plated Gold: Excellent wear and corrosion resistance, suitable for high reliability, frequent plugging and unplugging, or harsh environments.

Low-quality products: thin and uneven coatings with poor adhesion, which wear or oxidize quickly, leading to a sharp increase in contact resistance.

2. Design and Craftsmanship: Transforming Material Properties into Reliable Connections

Good materials require good design and craftsmanship to achieve.

Contact Design:

Pressure and Area: The spring or screw structure must provide sufficient, stable, and uniform contact pressure. Insufficient pressure results in high contact resistance, while excessive pressure may cause plastic deformation of the cable or spring, leading to failure.

Contact point protection: The design should minimize the erosion of contact points by environmental factors (dust, moisture, corrosive gases).

Structural Strength and Insulating Materials:

Insulated housing: Must be made of flame-retardant, high-temperature-resistant, and high-CTI (Comparative Tracking Index) engineering plastic (e.g., PA66+GF). Inferior plastics are prone to aging, deformation, or even combustion, which can cause short circuits or fires.

Mechanical strength: Structures such as clips, guide rail grooves, and screw mounting seats must be robust and capable of withstanding stresses from installation, operation, and vibration.

Process consistency:

Precision Machining: Ensure consistent dimensions and tight tolerances at every contact point.

Reliable fasteners: The strength of screws, thread accuracy, and anti-loosening designs (such as screws with saddle washers) are crucial.

Conclusion: Terminal blocks are the "gatekeepers" of system safety

In modern electrical and control systems, although terminal blocks are inconspicuous passive components, they undertake multiple key functions such as current transmission, signal connection, circuit isolation, and physical fixation.

High quality terminal block: Like a loyal "goalkeeper", it ensures low loss, zero distortion, and high reliability of electrical energy and signals, resists environmental erosion and mechanical stress throughout the entire life cycle of the equipment, and is the cornerstone of safe, stable, and efficient system operation.

Low quality terminal block: It is a hidden time bomb in the system. The small cost savings it saves are completely insignificant compared to the potential costs of equipment damage, production downtime, data loss, and even personal safety accidents.

Therefore, when choosing a terminal block, it must not be regarded as a simple "wiring tool". The strict requirements for its materials (conductivity and coating), design (contact and insulation), and process (consistency) are the basic guarantees for the investment and personal safety of the entire electrical system. Always adhere to selecting products that comply with international standards (such as UL, IEC, VDE) and come from reliable manufacturers, which is the wisest choice.
