This terminal block is equipped with a side screw connection system, ensuring strong wire fastening, vibration resistance, and long-term stability. It is widely used in power supplies, control systems, automation equipment, industrial machinery, and communication devices, offering both mechanical reliability and electrical performance.
Item No :
H2EDGBM-5.08Payment :
T/TProduct Origin :
ChinaColor :
green ,we can also make other color if meet moqPCB Pin Terminal Block 5.08mm Pitch with Side Screw
The PCB Pin Terminal Block 5.08mm Pitch with Side Screw is a reliable and durable connector solution designed for secure wire-to-board connections in electronic and industrial applications. With a standard 5.08mm pitch, it provides excellent spacing for stable current transmission and easy integration into printed circuit boards.
Product Features:
1.Type and Pole
Type: Pcb Pluggable Screw Terminal Block
Pole:
| 2 pin terminal block | 3 pin terminal block | 4 pin terminal block | 5 pin terminal block | 6 pin terminal block | 7 pin terminal block |
| 8 pin terminal block | 9 pin terminal block | 10 pin terminal block | 11 pin terminal block | 12 pin terminal block | 13 pin terminal block |
| 14 pin terminal block | 15 pin terminal block | 16 pin terminal block | 17 pin terminal block | 18 pin terminal block | 19 pin terminal block |
| 20 pin terminal block | 21 pin terminal block | 22 pin terminal block | 23 pin terminal block | 24 pin terminal block |
2.Material Of Pluggable Terminal Block
| Housing | PA66, UL94V-0 |
| Pin Header | Copper alloy ，ag plated |
3.Electrical Of Pluggable Terminal Block
| Rated Voltage |
UL IEC 300V 320V |
| Rated Current | 15A 20A |
| Contact resistance | 20mΩ |
| Insulation resistance | 500MΩ/DC500V |
| Withstanding voltage | AC 2000V/1 Min |
4.Mechanical Of Pluggable Terminal Block
| Temp. Range | -40℃~ +105℃ |
| MAX Soldering | +250, for 5 Sec. |
